PROXIMITY SWITCHES
PROXIMITY SWITCHES

PROXIMITY SWITCHES

Proximity Switches are synonymous with USP Safety Switches. We are a pioneer and respected leader in the industry. Our switch products are made with high-grade industrial materials, they are hand-assembled, and every switch is tested to ensure optimum performance... read more

156fd1_8c3867a3bec84663a194abd03adadc18_

MODEL 90-SP

  • 90-SP (Micro Mini)

  • 1/4’x1/4”

  • .60 Operating Distance

  •  SPST NO.

  • Super Wide 1.75”

  • 24” Lead.

MODEL 110-SP

  • 1/4’x1/2” Super Mini Magnet.

  • .60 Operating Distance

  • SPST NO.

  • Available in white.

  • 24” Lead.

156fd1_277f1b4c9e9e45bf8ed4786f36a1e4cc_

MODEL 130-SP

  • 3/8x1/2 Super Stubby Press

  • Break Away Flange

  • 1 Inch Operating Distance

  • Super Wide 1.50” Operating Distance

  • SPST NO.

  • 24” Lead.

MODEL 135-SP

  • Mini Stick-on Contact.

  • 1” Operating Distance

  • Break Away Flange

  • 1/2”x3/8”x1-1/4”

  • SPST NO

  • .5” Operating Distance

  • 135SPDT Available

156fd1_6943a23631554700a37d28bc012b5512_
156fd1_9ca068046fd5457495612b13f6619ee0_

MODEL 140-SP

  • 3/8 x 1-1/8”.

  • .75 Inch Operating Distance

  • SPST NO

  • 24” Lead

MODEL 150-SP

  • 3/8 x1/2 Fit x 1-1/8”.

  • .60 Inch Operating Distance

  • Super Wide 1.50” Operating Distance

  • OC SPDT.

  • 24” Lead.

  • 3/4 Metal Mountable

156fd1_bc08e76c90244db89c333bddd4ee3b51_
156fd1_f57cab6af73745d1b7021d147011c8ac_

MODEL SP200

  • 3/4” Steel Door Contact

  • .75” Operating Distance

  • Concealed Contact 3/4”x1-1/4”.

  • Black, Brown, or White.

  • Rhodium Metal Contacts

  • Rare Earth Magnets24” Wire Lead -22awg.

  • Closed Circuit,

  • Also Available in NO SPDT

MODEL 240

  • 5 Inch Operating Distance

  • Size 1/4”x 1/2”

  • SPST NO

  • 24” Leads

156fd1_7dd69cd19fa24ad1b46bbca3e6b745df_
156fd1_9b863eb55ad24478abf5656c2c79846d_

MODEL 240-8

  • 1” Operating Distance

  • Size: 2-5/8”x1/2”x1/2”

  • NO & OC

  • Premier Surface Contact

MODEL 260

  • Up to .675” Operating Distance

  • 3/8” x 5/8”

  • Closed Circuit

  • 24” Leads

  • Approved by CA Fire Marshal for fire doors

156fd1_aef0efa0315a44f7ade5da35c6d9ebbc_

MODEL 260-8

  • Industrial Contact

  • Metal Enclosure

  • Stainless Steel

  • Armored Cable 24" L

  • 1" x 1/2" x 3"

  • 500-SPCC - 2.5" Operating Distance

  • 500-SPOC - 2" Operating Distance

  • 500-SPDT - 2" Operating Distance

MODEL 500-SP

  • Industrial Contact

  • Metal Enclosure

  • Stainless Steel

  • Armored Cable 24" L

  • 1" x 1/2" x 3"

  • 500-SPCC - 2.5" Operating Distance

  • 500-SPOC - 2" Operating Distance

  • 500-SPDT - 2" Operating Distance

156fd1_8c748d1077d74d23b9a1c4c9fcc78150_
